SPECIFICATIONS :
|
Power Supply |
220/380V |
|
Working Air Pressure |
0.7-0.8 MPa |
|
Power |
1.1/0.75 Kw |
|
Rim Diameter |
11 – 22’’ |
|
Rim Width |
4” – 15” * |
|
Max. Wheel |
38” (980 mm) |
|
Rim Width |
3" - 12" (75 - 305 mm) |
|
Average Rotate speed |
6.8 rpm |
|
Shovel force |
2000 Kg. |
|
Gross/Net Weight |
260/220 Kg. |
|
Dimension |
1150 x 1000 x 960 mm |
|
|
Features
|
|
|
|
Foot valve adopts stainless steel valve rod
|
|
|
