SPECIFICATIONS :
|
Power Voltage |
110V/60 hz/1 Ph/1.1 Kw
220V/50 Hz/1 Ph/1.1 Kw
380V/60 Hz/3 Ph/0.75 Kw |
|
Working Air Pressure |
0.8-1.0MPa (115 145 PSI) |
|
Rim Diameter |
Inner 12" 18"(305 457mm)
Outer 10" 16"(255 405mm) |
|
Rim Width |
3” – 12” (75 305mm) |
|
Max. Wheel |
38” (980 mm) |
|
Average Rotate speed |
6.8 rpm |
|
Shovel force |
2000 Kg. |
|
Net Weight |
200 Kg. |
|
Packing Dimension |
1000 x 920 x 980 mm |
|
|
Features
|
|
|
|
Foot valve adopts stainless steel valve rod
|
|
|
