TECHNICAL SPECIFICATIONS :
|
Motor power |
.75kw/0.55kw/1.1kw |
|
Power supply |
220V/400V/110V |
|
Max. wheel diameter
|
45”(1143mm) |
|
Max. wheel width |
16”(406mm) |
|
Outside clamping |
12”~23” |
|
Inside clamping
|
14”~26” |
|
Air supply |
8bar |
|
Bead breaker force
|
2500kg |
|
Noise level |
75dB |
|
Weight |
330/285kg |
|
Package size(main body) |
1130*900*1030mm |
|
Package size(help arm) |
1230*450*350mm |
|
|
Features
|
|
|
|
Full automatic pneumatic tilting arm with pneumatic lock
|
|
|
|
Bigger and bending 360 degree special rotary type shovel press the tyre at any angle |
|
|
|
High strength steel pedal |
|
|
|
Central positioning device make the tyre and turntable keep in one concentric circle |
|
|
|
26” large turntable and powerful motor, suitable for low profile tyre |
